The LTC Automatic Cereal Bar Packaging Line connects directly to your cooling tunnel, replacing manual handling. Featuring a smart aligning and sorting system, it gently separates fragile granola and crisp rice bars without breakage. Reduce labor costs by 3-5 workers while boosting efficiency.
Manual feeding leads to high breakage rates for fragile granola bars and limits your production speed. The LTC Automatic Packaging Line offers a contactless solution. By utilizing multi-stage differential speed belts, the system automatically arranges, distances, and feeds bars into the Flow Wrapper with zero pressure.
Direct Integration: Seamlessly connects to the output of your cooling tunnel or guillotine cutter.
Zero-Pressure Handling: Uses smart sensors and speed-adjusting belts to prevent bars from colliding or overlapping.
Multi-Belt Distributing: Automatically diverts bars to different wrappers if one machine stops, ensuring non-stop production.
Food Grade Design: Belts allow for easy tool-free removal for quick cleaning and hygiene maintenance.
Designed specifically for sticky or fragile rectangular products:
Granola Bars / Muesli Bars
Crisp Rice Treats
Peanut Brittle / Sesame Snaps
Protein Bars (High viscosity)
Production Capacity | 80-120 per/min | |
Packing material | ET+OPP, BOPP, CPP, PET+AL, and other one layer or double layer heated complex film. | |
Applicable Range | 1 pieces N95/KN95/Flat face mask | |
Packing | The length of the bags | 100-280mm |
Width (mm) | 85-160mm | |
Height (mm) | 1-8mm | |
Max. Width of film | 400mm | |
Max. Dia of film | Ф400mm | |
Total power | 10 kw | |
Power supply | AC380V 50HZ 3P | |
Gross weight | 2000kg | |
Overall diamensions(mm) | 6400*1700*1900mm | |
